产品概述

增量型旋转编码器 EF 36 K，增量型旋转编码器带换相信号。技术原理：光电式；外径：37；轴径：8, 9,52, 10；分辨率：1024~500；防护等级：40。

规格参数

Tipology	Rotary with bearing
Category	Incrementals
Mechanics	Blind / Through hollow shaft
Technology	Optical
Size [mm]	37
Shaft [mm]	8, 9,52, 10
Resolution [ppr]	Da 1024A 500
IP	40
Output interface	Line Driver RS-422NPN Open Collector
Hall signals	Yes
Markings / Certifications	CE / UKCA, UL / CSA
Operating temperature [°C]	-10 ... 85

分辨率：1024~500；输出接口：线驱动RS-422/NPN开路集电极；防护等级：40；轴径：8, 9,52, 10；技术原理：光电式
